Aerie Slim, Rotationally symmetric optic
ARS 18L70-740 RS CL-D CL1 W5 T76 ANT
Article number: 96632926
EAN number: 9010299126542
Technical Data
Electrical Properties
EEC
D
Luminaire input power
39 W
Power factor
0.97
Rated voltage
220 - 240 V
Ballast
Ballast 1: 1 x 87500877 LCO 40/200-1050/64 NF C ADV3
Safety Class
SC1
Dim Control
Dimming programmable
Emergency included
true
Light Distribution
Light Source
LED
Luminaire luminous flux
4977 lm
Luminaire efficacy
128 lm/W
Filterable Correlated Colour Temperature
4000 K
Chromaticity tolerance (initial MacAdam)
5
Colour Rendering Index min.
70
Light Distribution
STD - standard
Beam Angle
radially symmetric
Physical Characteristics
Dimensions
Ø[602]x[586] mm
Mounting type
Outdoor post top
Length
602 mm
Width
602 mm
Height
586 mm
Weight
11.24 kg
Colour
Anthracite
Impact strength
IK10
Degree of protection
IP66
Pole Diameter
76 mm
Reflector Color
Die-cast
Maintenance and Protection
Rated Median Useful Life
L90 100000 h Rated useful life (B10) 50 °C
L95 100000 h Rated useful life (B10) 25 °C
Norms and Standards
Certificates
Downloads
Design Data
DatasheetCombination DatasheetFamily datasheetCircuit breaker dataRCM Declaration of ConformityCE / UKCA - Declaration of ConformityCB CertificatePhotometric LDTPhotometric IESTransfer to DIALuxTransfer to ReluxTransfer to ecoCALC, VIVALDI, DALEC or HILITE2D CAD drawing18.52 kB
29.04 kB
Accessories
ARS 18L70-740 RS CL-D CL1 W5 T76 ANT
A discreet, post top LED lantern with a timeless design. LED driver for 18 LEDs, driven at 700mA with radially symmetric distribution. Class I electrical, IP66, IK10. Canopy and base: corrosion resistant Die-cast powder coated aluminium suitable for C5 environments, finished textured anthracite (close to RAL7043). Enclosure: slim UV stabilised polycarbonate with clear finish. Fitted with internal diffuser to reduce glare. Complete with 4000K LED. Post top mounting to Ø76mm column. Pre-wired with 5m cable.
Dimensions: Ø602 x 586 mm
Luminaire luminous flux: 4977 lm
Luminaire efficacy: 128 lm/W
Weight: 11.24 kg
Scx: 0.172 m²
